In-Wall CCTV Flat Panel Monitor - Security Surveillance Video Display Screen with HD 1080p Support (9.0'' -inch Display)
Model PLVW92U
Brand Pyle
Category TVs - Monitors
MSRP $248.99
Warranty 1 Year

Details

  Features:
  • Universal CCTV Video Display Monitor System
  • Used for Security Surveillance Monitor Applications
  • Supports HD 1080p Video Signal
  • Custom In-Wall Panel Mount
  • Flat Panel, Widescreen LCD Display
  • Front Panel Button Control Center
  • HDMI, VGA, (2) x RCA Video Input Connectors
  • RCA (L/R) Audio Output Connector Jacks
  • Selectable Video Input Channels
  • Brightness, Contrast, Hue, Saturation Adjustable
  • Decorative Removable Screen Display Frame Cover
  • Rugged Metal Display Panel Monitor Housing
  • *Power Supply Cable Available (Sold Separately, Model: PS5A)

    What's in the Box:
  • Flat Panel Monitor
  • Decorate Frame Cover
  • Remote Control
  • Mounting Hardware

    Sizes / Dimensions:
  • Cut-Out Dimensions (L x W x D): 10.3'' x 7.2'' x 1.5'' -inches
  • Total Unit Size with Frame (L x W x D): 9.8'' x 6.8'' x 1.5'' -inches
  • Total Unit Size with without Frame (L x W x D): 9.7'' x 6.0'' x 1.2'' -inches

    Technical Specs:
  • Video Display Screen Size: 9.0'' -inches
  • HDMI Support: 1080p, 1080i, 720p, 480p, 576p
  • Native Resolution: 800 x 480 (RGB) Pixels
  • Contrast Ratio: 900:1
  • Brightness: 400 cd/m
  • Video System: PAL/NTSC Auto Color
  • Screen Aspect Ratio Selectable - 16:9 / 4:3
  • Power Consumption: <5.5 Watt
  • Amperage Draw: 3A
  • *Not Intended for Continuous/24 Hour Powered-ON Applications
  • Power Supply: DC 12V
  • Sold as: Unit
  • Weight: 4.25 lbs.
  • Videos

    No Videos Available

    Manuals and Downloads

    PLVW92U - Manuals

    Reviews

      No User Review Available


    Sign in to Add Review



    Similar Products

    Untitled Document
    flat; panel; monitor; screen; display; custom; install; installation; cut; out; wall; console;

    Add Video Anywhere

    The Pyle PLVW flat panel monitors provide vivid & crisp widescreen picture quality. The integrated metal support frame and extra thin display housing makes them perfect for any wall or flat surface application. You will be able to create a clean and professional looking custom video screen install whether at home, in the office or in the vehicle.

    HDMI Video Support - Stream it All
    • 1080p
    • 1080i
    • 720p
    • 480p
    • 576p

    Universal Application Display Monitors

    Used for Security, Surveillance, Business, Entertainment

    The video system mounts in-wall or in-console, so it will sit flush with your wall surface. It also includes a decorative frame that covers the screen housing for completing the 'clean look' install. The cover frame will still provide convenient access to the front panel control buttons. Whether used for work or play, these versatile panel monitors will deliver hi-res picture with impressive sharpness, clarity and brightness.

    • PAL/NTSC Auto Color System
    • Aspect Ratio Selectable - 16:9 / 4:3
    • Includes Wireless Remote Control, Cut-Out Template, Mounting Screws
    • Steel Monitor Housing Frame & Cut-Out Holes for Easy Mounting

    Tailor Made Video on Demand

    Connection Interface

    Connect your system using the inputs: (2) RCA video, (1) HDMI and (1) VGA connector; it also features RCA audio (L/R) connector jacks for connection to an external sound system.

    Front Panel Button Control

    Use the included remote control or the front panel buttons to control the panel monitor. Quickly switch between the input sources or adjust menu display settings.

    Wiring Diagram

    Multiple source input configuration will allow you to create a truly unique video display presentation. Connect multiple display screens or additional video sources.

    Removable Plate Frame

    The decorative plate frame is easily removable so your panel monitor is accessible at all times. Use the system with or without the plate frame, depending on your installation & setup.

    Add Video Anywhere

    The Pyle PLVW flat panel monitors provide vivid & crisp widescreen picture quality. The integrated metal support frame and extra thin display housing makes them perfect for any wall or flat surface application. You will be able to create a clean and professional looking custom video screen install whether at home, in the office or in the vehicle.

    PLVW92U PLVW125U PLVW154U PVLW194U
    Diagonal Screen Size: 9.0'' 12.5'' 15.4'' 19.0''
    HDMI, VGA, RCA Connectors:
    Full HD 1080p Support
    Cut-Out Dimensions:
    (L x W x D)
    10.3'' x 7.2'' x 1.5'' 14.0'' x 9.5'' x 1.5'' 15.7'' x 11.2'' x 1.5'' 13.4'' x 18.5'' x 1.5''
