Details
|
|
500 Watts x 2 RMS Power @ 4 Ohms
1000 Watts x 2 Max Power @ 4 Ohms
2000 Watts x 1 Max Power @ 4 Ohms Bridged
750 Watts x 2 Watts RMS Power @ 2 Ohms
Electronic Crossover Network
Bass Boost Circuit
Bridgeable at 4 Ohms
2 Ohm Stereo Stable
Double Sided Epoxy PCB Circuit Board
Gold Plated RCA Inputs
Line Outs for Left and Right Channels
Low Pass Filter Controls
High Pass Filter Controls
Subwoofer Remote Level Control
Power and Protection LED Indicators
Soft Turn On/Off
Minimum Speaker Impedance: 2 Ohms
THD: 0.04%
S/N Ratio: 100dB
Channel Separation: 60dB
Frequency Response: 10Hz - 35kHz
Variable Low Pass Filter: 50Hz~120Hz, 24dB/Octave
Variable High Pass Filter: 50Hz~750Hz, 24dB/Octave
Variable Bass Boost: 0 to 18dB
Input Sensitivity: 200mV ~ 8V
Fuse Rating: 40A x 4
Dimensions: 10.08'' (W) x 2.12'' (H) x 23.22'' (L) Sold as: UnitWeight: 22.14 lbs.
|
|
